Home » Products » DGSL-20-30-PA

DGSL-20-30-PA

DGSL-20-30-PA

$827.86

Mini Slide is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:DGSL-20-30-PA

FESTO Order Number:544007

SKU: DGSL-20-30-PA Category: Tag:

Description

Stroke [mm] 30
Alignable end position range / Length front [mm] 50,5
Alignable end position range / Length rear [mm] 49,5
Piston diameter 25 mm
Operating mode actuator unit Joch
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Guide Ball cage guide
Construction set up JochKolbenKolbenstangeSchlitten
Position detection For proximity switch
Operating pressure [bar] 1 to 8
Max. speed [m/s] 0,8
Repeatability 0.3 mm
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 0 – No corrosion stressing
ambient temperature [??C] 0 to 60
Impact energy at the end positions [J] 0,450
Dampening length [mm] 1,2
Max. force Fy [N] 3.354
Max. force Fz [N] 3.354
Max. torque Mx [Nm] 60
Max. torque My [Nm] 30,0
Max. torque Mz [Nm] 30,0
Theoretical force at 6 bar, Return flow [N] 247
Theoretical force at 6 bar, flow [N] 295
Moving mass [g] 750
Product weight [g] 1.910
Alternative connections See product drawing
Fastening type With throughway bores
Pneumatic connection G1/8
Material information Copper and PTFE-freeRoHs compliant
Cover material Aluminium wrought alloy
Seals material HNBR
Housing material Aluminium wrought alloy
Piston rod material High-alloyed stainless steels
