Home » Products » DHTG-65-24-A

DHTG-65-24-A

DHTG-65-24-A

$2,787.16

Rotary Indexing is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:DHTG-65-24-A

FESTO Order Number:548081

SKU: DHTG-65-24-A Category: Tag:

Description

size 65
Parallelity plate [mm] <= 0,04 mm Plan run plate [mm] <= 0,02 mm Concentricity plate [mm] <= 0,02 mm Repeatability of the swivel angle [deg] <= 0,03 deg Dampening YSRJ: Shock absorber, hard characteristic curve, Alignable installation position arbitrary Principle of operation double acting Construction set up Toothed rack/pinionForce controlled movement cycleSprocket coupling Position detection For inductive sensors Partition 24 Operating pressure [bar] 4 to 8 Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Information about operating and control medium Oiled operation possible (required in further operations) Corrosion resistant class KBK 2 - moderate corrosion stress Sound level [dB(A)] <= 70 dB(A) ambient temperature [??C] 5 to 60 Max. axial force static [N] 1.000 Max. tilting torque static [Nm] 100 Max. radial force static [N] 2.000 Max. tangential torque static [Nm] 100 Theoretical torque at 6 bar [Nm] 2,1 Product weight [g] 1.900 Fastening type With Throughway bore and centring sleeve Pneumatic connection female thread M5 Plate material Zinc plated steel Material information Copper and PTFE-freeRoHs compliant Stoppers material Zinc plated steel Cover material Aluminium wrought alloy Seals material NBRTPE-U(PU) Housing material Aluminium wrought alloy
