EGSL-BS-35-50-8P

EGSL-BS-35-50-8P

$1,676.52

Mini Slide is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:Egsl-Bs-35-50-8P

FESTO Order Number:562160

SKU: EGSL-BS-35-50-8P Category: Tag:

Description

Working stroke [mm] 50
size 35
Running parallelity in z-direction [mm] 0,02
Parallelity [mm] 0,050
Reversing play [??m] <= 50 ??m Spindle diameter [mm] 8,0 Spindle pitch [mm/U] 8,0 installation position arbitrary Guide Ball cage guide Construction set up GuideElectrical mini-carriageWith Ball screw drive Motor type Step motorServo motor Spindle type Ball screw drive Position detection For proximity switch Max. acceleration [m/s2] 25 Max. speed [m/s] 0,50 Repeatability ??0.015 mm Power-on time 100 % Corrosion resistant class KBK 0 - No corrosion stressing Sound level [dB(A)] 60 Protection category IP40 ambient temperature [??C] 0 to 60 Continuous feed force [N] 50 Max. actuator torque [Nm] 0,20 Max. force Fy [N] 412 Max. force Fz [N] 412 Max. torque Mx [Nm] 6,2 Max. torque My [Nm] 6,0 Max. torque Mz [Nm] 6,0 Max. radial force on drive shaft [N] 20 Max. feed force Fx [N] 75 Empty run actuator torque [Nm] 0,015 Guideline payload, horizontal [KGM] 2 Guideline payload, vertical [KGM] 2 Mass inertia JL per kg usable load [kg/cm2] 0,01620 Mass inertia JO [kg/cm2] 0,0426 Feed constant [mm/U] 8,0 Maintenance interval Lifetime lubrication Moving mass [g] 270 Product weight [g] 570 Fastening type With female threadWith Centring sleeveWith Accessories Material information LABS containing materials includedRoHs compliant Cover material Cast aluminiumpainted Guide carriage material Roller bearing steel Housing material Aluminium wrought alloyanodized Joch plate material Aluminium wrought alloyanodized Spindle nut material Roller bearing steel Spindle material Roller bearing steel
