Description
size 25
Construction set up Electro-mechanical rotary driveWith Integrated drives
installation position arbitrary
Fastening type with female thread
Angle of rotation Endless
Gear ratio 9:1
Nominal torque [Nm] 2,50
Nominal rotational speed [1/min] 66
Max. speed [1/min] 150
Torsional play [deg] 0,2
Repeatability ?I0.05 ??
Max. axial force [N] 350
Max. radial force [N] 450
Permitted mass moment of inertia [kg/m2] 0,0065
Product weight [g] 1.350
Step angle at full step [deg] 1,8
Step angle tolerance ?I5 %
Mass inertia JO [kg/cm2] 0,1140
Power-on time 100 %
Nominal operating voltage DC [V] 24
Nominal current motor [A] 3,0
Insulation protection class B
Motor type Step motor
Rotor position transducer Incremental encoder
Rotor position transducer interface RS422 TTL AB channel + null index
Rotor position transducer measurement principle Visual
Electrical connection technology Plug
CE certificate (see declaration of conformity) to EU EMC directive
Interface code basis E8-55
Protection category IP40
ambient temperature [??C] 0 to 50
Relative humidity 0 – 85 %Not condensing
Material information LABS containing materials includedRoHs compliant
Flange material Aluminium wrought alloyanodized
Housing material Aluminium wrought alloyanodized
