Home » Products » ESBF-BS-100-300-40P

ESBF-BS-100-300-40P

$3,829.09

Electric Cylinder is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:Esbf-Bs-100-300-40P

FESTO Order Number:574124

SKU: ESBF-BS-100-300-40P Category: Tag:

Description

size 100
Stroke [mm] 300
Piston rod thread M20x1,5
Reversing play [??m] 40
Spindle diameter [mm] 40
Spindle pitch [mm/U] 40,0
Max. twist angle of the piston rod ?I [deg] 0,50
Based on standard ISO 15552
installation position arbitrary
Piston rod end Male thread
Motor type Servo motor
Position detection For proximity switch
Construction set up Electro-cylinder with ball screw thread
Spindle type Ball screw
Anti-twist lock / guide Slide guided
Max. acceleration [m/s2] 25,0
Max. speed [m/s] 1,340
Repeatability ?I0.01 mm
Power-on time 100 %
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -20 to 60
Food compatibility See expanded material information
Relative humidity 0 – 95 %
Protection category IP40
ambient temperature [??C] 0 to 60
Max. actuator torque [Nm] 102,6
Max. radial force on drive shaft [N] 1.100
Max. feed force Fx [N] 14.500
Empty run actuator torque [Nm] 1,00
Guideline payload, horizontal [KGM] 1.400
Guideline payload, vertical [KGM] 1.400
Mass inertia JH per metre stroke [kg/cm2] 20,3720
Mass inertia JL per kg usable load [kg/cm2] 0,40528
Mass inertia JO [kg/cm2] 6,17040
Moving mass at 0 mm stroke [g] 8.786
Weight supplement per 10 mm stroke [g] 193
Base weight at 0 mm stroke [g] 11.123
Supplement moved mass per 10 mm stroke [g] 132
Fastening type With female threador accessory
Interface code actuator D100
Material information LABS containing materials includedRoHs compliant
Cover material Cast aluminiumCoated
Piston rod material High-alloyed stainless steels
Screws material Steelzinc plating
Spindle nut material Roller bearing steel
Spindle material Roller bearing steel
Cylinder tube material Aluminium wrought alloySmooth anodised
