Description
installation position arbitrary
Construction set up Branching module
Operating pressure [bar] 0 to 12
Normal nominal flow in main flow direction 1 -> 2 [l/min] 20.000
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]Inert gases
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -10 to 60
Air purity class at the output Compressed air to ISO 8573-1:2010 [7:-:-]Inert gases
Medium temperature [??C] -10 to 60
ambient temperature [??C] -10 to 60
Product weight [g] 822
Pneumatic connection 3 G3/4
Pneumatic connection 4 G1/4
Material information Copper and PTFE-freeRoHs compliant
Housing material Aluminium die casting
