HGPT-80-A-B-F

HGPT-80-A-B-F

$2,476.33

Parallel Gripper is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:HGPT-80-A-B-F

FESTO Order Number:560237

SKU: HGPT-80-A-B-F Category: Tag:

Description

size 80
Stroke per gripper jaw [mm] 12,5
Max. exchange precision [mm] <= 0,2 mm Max. gripper jaw play ax, ay [deg] <= 0,1 deg Max. gripper jaw play Sz [mm] <= 0,02 mm Rotational symmetry [mm] <= 0,2 mm Repeatability grippers [mm] <= 0,05 mm Quantity Gripper jaws 2 installation position arbitrary Principle of operation double acting Gripper function Parallel Construction set up Inclined planeForce controlled movement cycle Position detection For proximity switch Open total gripping force at 6 bar [N] 6.550 Close total gripping force at 6 bar [N] 6.300 Operating pressure [bar] 3 to 8 Operating pressure blocking air [bar] 0 to 0.5 Max. working frequency gripper [Hz] <= 2 Hz Min. opening time a 6 bar [ms] 212 Min. closing time at 6 bar [ms] 211 Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Information about operating and control medium Oiled operation possible (required in further operations) Corrosion resistant class KBK 2 - moderate corrosion stress Protection category IP40 ambient temperature [??C] 5 to 60 Open gripper jaws at gripping force of 6 bar [N] 3.275 Close gripper jaws at gripping force at 6 bar [N] 3.150 Mass inertia [kg/cm2] 150,515 Max. force on gripper jaws Fz static [N] 7.000 Max. torque on gripper jaws Mx static [Nm] 180 Max. torque on gripper jaws My static [Nm] 220 Max. torque on gripper jaws Mz static [Nm] 170 Lubrication interval guide elements [Mio SP] 5 Max. mass per external griper finger [g] 1.830 Product weight [g] 4.745 Fastening type With Throughway bore and dowel pinWith Female thread and dowel pinSelectively:Female thread and centring sleeveWith Throughway bore and centring sleeve Pneumatic connection blocking air M5 Pneumatic connection G1/4 Material information Copper and PTFE-freeRoHs compliant Cover cap material High-alloyed stainless steels Housing material aluminiumanodized Gripper jaws material hardenedSteel
