MHE2-MS1H-5/2-M7

MHE2-MS1H-5/2-M7

$157.80

Solenoid Valve is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:MHE2-MS1H-5/2-M7

FESTO Order Number:525113

SKU: MHE2-MS1H-5/2-M7 Category: Tag:

Description

Valve function 5/2 monostable
Actuation type Electrical
Build.width [mm] 10
Normal nominal flow [l/min] 90
Operating pressure [bar] -0.9 to 8
Construction set up Pressure-relieved poppet valve
Reset mode Mechanical spring
Protection category IP65
Permission RCM markc UL us – Recognized (OL)
Nominal width [mm] 2
Pitch dimension [mm] 14
Exhaust function Can be throttled
Sealing principle Soft
installation position arbitrary
Hand assist actuation tentative
Control type Direct
Flow direction Not reversible
??berdeckung negative ??berdeckung
Max. switching frequency [Hz] 300
Shifting time off [ms] 1,7
Shifting time on [ms] 1,9
Power-on time 100 %
Coil characteristic value 24 V DC: Low current phase 1.625 W, high current phase 6,5 W
Permitted voltage oscillations ?? 10 %
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Oscillation strength Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6
Shock resistance Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistant class KBK 2 – moderate corrosion stress
Medium temperature [??C] -5 to 60
ambient temperature [??C] -5 to 60
Product weight [g] 70
Electrical connection 2 pinPlug
Fastening type With throughway bores
Pneumatic connection 1 M7
Pneumatic connection 2 M7
Pneumatic connection 3 M7
Material information Copper and PTFE-freeRoHs compliant
Seals material HNBRNBR
Housing material CoatedZinc pressure cast
Screws material Steelzinc plating
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directive
Reverse polarity protection Bipolar
Additional functions Spark suppressionHolding current reductionprotection circuit
Tolerance shifting time off +10 %/-30 %
Tolerance shifting time on +10%/-30%
Shifting time scatter from 1 Hz [ms] 0,2
Limits ambient and media temperature Depending on the switching frequency
Pneumatic connection 4 M7
Pneumatic connection 5 M7
Max. tightening torque screw connection [Nm] 2,0
