Description
Data backup Flash memory
Control signal Output error readyOutput position 1/2/3/4Input position 1/2/3/4Input remote / teach / left / right
Display 3 digitsRed colourSeven segment display
Operating element 3 buttonsFoil keyboard
Output fuses Electronicmax. trigger current 500 mAVia sum of all outputs
Quantity digital outputs 5
Quantity digital inputs 8
Design outputs No galvanic separationacc. to IEC 61131-2Positive logic (PNP)
Design inputs No galvanic separationacc. to IEC 61131-2Positive logic (PNP)
Debounce time inputs [ms] 20
Max. power input with proportional valve [A] 1,1
Max. power input without proportional valve [mA] 80
Nominal operating voltage DC [V] 24
Power consumption input [mA] 4
Current carrying capacity per output [mA] 100
Permitted voltage oscillations ?I 25 %
Permission RCM mark
CE certificate (see declaration of conformity) to EU EMC directive
Continuous impact strength DIN&EC 68 parts 2-82 Tested to severity class 2
Relative humidity 0 – 95 %Not condensing
Protection category IP65acc. to IEC 60529
Oscillation strength to DIN/IEC 68 part 2-6 Tested to severity class 1
ambient temperature [??C] 0 to 50
Product weight [g] 400
Electrical connection type SUB-D15 pinPlug
Electrical connection: proportional valve M97-poligDose
Electrical connection: path measurement system M128 pinsocket / container / ??.
