Home » Products » SRBG-C1-N-1-P-C2-C2

SRBG-C1-N-1-P-C2-C2

$211.62

Limit Switch is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:SRBG-C1-N-1-P-C2-C2

FESTO Order Number:3568165

SKU: SRBG-C1-N-1-P-C2-C2 Category: Tag:

Description

Design Angular
Based on standard EN 60947-5-2VDI/VDE 3845
Permission RCM markc UL us (OL)
CE certificate (see declaration of conformity) to EU EMC directive
KC-mark KC-EMV
Material information LABS containing materials includedRoHs compliant
Measurement principle Inductive
ambient temperature [??C] -25 to 70
Control output PNP
Switching element function NO contact
Max. switching frequency [Hz] 500
Max. output current DC [mA] 100
Operating voltage range DC [V] 10 to 30
Empty run current [mA] <= 25 mA Electrical connection: input Spring tension clamp Electrical connection: outlet Spring tension clamp installation position arbitrary Product weight [g] 170 Housing material PBT Screws material High-alloyed stainless steels Operation-readiness display LED green Switching status indicator LED yellow Status display LED yellow = Valve switching status Bearing temperature [??C] -25 to 70 Protection category IP67 Shock resistance Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 Oscillation strength Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 Degree of contamination 3 Voltage drop [V] <= 3 V Residual current [mA] 0 to 0.5 Short circuit resistance Cycling Reverse polarity protection for all electrical connections Lockable conductor nominal cross-section [mm2] 0.2 to 2.5 Cable screwing M12x1,5M20x1,5
