Description
installation position arbitrary
Operating pressure [bar] 4 to 8
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation not possible
Corrosion resistant class KBK 0 – No corrosion stressing
Protection category IP65
ambient temperature [??C] 0 to 50
Product weight [g] 1.120,0
Fastening type on connection plate
Housing material Aluminium wrought alloy
Pneumatic connection 1 Connection plate Size 26 mm to ISO 15407-2
Material information RoHs compliant
Nominal width laval nozzle [mm] 2
Construction type silencer type open
Reverse polarity protection for all electrical connections
Ejector characteristic High vacuumStandard
Hand assist actuation RatchetingCoveredtentative
Integrated function check valvesSilencer openvacuum switchElectrical switch on valveEjection impulse electricalflow control valve (both directions)Air-saving function electrical
Construction set up Not modular
Short circuit resistance yes
Measured parameter Relative pressure
Measurement principle Piezoresistive
Switch function Threshold comparator
Valve function 5/3 ventilated
Switching element function NO contact
Settings range hysteresis [bar] [bar] -0,9
Settings range threshold value [bar] -0,999
Nominal operating pressure [bar] 6
Operating voltage range DC [V] 21.6 to 26.4
Inductive protection circuit adjusted to MZ, MY, ME coils
Empty run current [mA] 50 to 150
Max. output current [mA] 50
Power-on time 100 %
Voltage drop [V] <= 1,5 V
Coil characteristic value 24 V DC: 1,3 W
Overload resistant Available
Medium temperature [??C] 0 to 50
Sound level [dB(A)] 78
Pressure measurement range [bar] -1
Accuracy FS [%FS] 3
Pneumatic connection 3 Connection plate Size 26 mm to ISO 15407-2
Seals material NBR
Screws material Steelzinc plating
Plug housing material nickel-platedZinc pressure cast
Plug contacts material brassGold plated
Window material PA
Button field material TPE-U
