VPPM-8L-L-1-G14-0L2H-LK-S1

$1,068.90

Proportional Pressur is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:VPPM-8L-L-1-G14-0L2H-LK-S1

FESTO Order Number:8024261

SKU: VPPM-8L-L-1-G14-0L2H-LK-S1 Category: Tag:

Description

Nominal width ventilation [mm] 8
Nominal width venting [mm] 7,0
Actuation type Electrical
Sealing principle Soft
installation position arbitrary
Construction set up Pre-controlled membrane control valve
Short circuit resistance for all electrical connections
Safety instructions Safety position VPPM: For supply line break, the output pressure is retained uncontrolled.
Reverse polarity protection for all electrical connections
Reset mode Mechanical spring
Control type pilot operated
Valve function 3-way proportional pressure regulator valve
Display type LED
Pressure regulation range [bar] 0.02 to 2
Input pressure 1 [bar] 0 to 4
Max. pressure hysteresis [bar] 0,01
Normal nominal flow [l/min] 650
Operating voltage range DC [V] 18 to 30
Max. power input [mA] 300
Power-on time 100 %
Max. electrical power consumption [W] 7
residual ripple 10 %
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]Inert gases
Information about operating and control medium Oiled operation not possible
Permission RCM markc UL us – Listed (OL)
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directive
Corrosion resistant class KBK 2 – moderate corrosion stress
Medium temperature [??C] 10 to 50
Protection category IP65
ambient temperature [??C] 0 to 60
Product weight [g] 560
Linearity error FS [%] 1
Temperature coefficient [%/K] 0,04
Repeatability FS [%] 0,5
Fastening type With throughway boresWith AccessoriesSelectively:
Pneumatic connection 1 G1/4
Pneumatic connection 2 G1/4
Pneumatic connection 3 G1/4
Material information RoHs compliant
Housing material Aluminium wrought alloyanodized
Report I-portIO-Link
IO-Link, report Device V 1.1
IO-Link, communication mode COM1 (4,8 kBaud), COM2 (38,4 kBaud), COM3 (230,4 kBaud)
IO-Link, port type A
IO-Link, process data width OUT 2 Bytes
IO-Link, process data width IN 2 Bytes
IO-Link, minimum cycle time 0.5 ms
