HEL-3/8-D-MINI FESTO Solenoid Valve: Precise Control with High-Efficiency Performance

In the field of automation control systems, solenoid valves are crucial components for achieving accurate fluid control. FESTO’s HEL-3/8-D-MINI solenoid valve, with its pneumatic actuation, soft sealing principle, and reliable performance, offers an ideal solution for pneumatic control. This article will detail the features and advantages of this solenoid valve.

Pneumatic Actuation and Soft Sealing

The HEL-3/8-D-MINI solenoid valve utilizes pneumatic actuation, using compressed air as the power source to achieve rapid response and precise control. The soft sealing principle ensures good sealing performance, reducing gas leakage and improving system efficiency.

Optional Installation Positions

The installation position of this solenoid valve can be chosen according to user needs, providing high flexibility to adapt to various installation environments and requirements.

Two-Way Two-Position, Normally Closed, Single-Stable Function

Featuring a two-way two-position, normally closed, single-stable valve function, the HEL-3/8-D-MINI solenoid valve can maintain a closed state without a control signal, ensuring system safety.

Wide Pressure Range

The working pressure range is from 0.3 Mpa to 1.6 Mpa (3 bar to 16 bar), suitable for various pressure requirements.

High Standard Flow Performance

Standardized according to DIN 1343, the rated flow rate is up to 1600 l/min, ensuring high-performance even with high flow demands.

Corrosion Resistance and Environmental Adaptability

The solenoid valve has a moderate corrosion resistance (CRC 2) and complies with the VDMA24364-B1/B2-L standard for paint wet defect substance (PWIS). It can operate stably in a medium and ambient temperature range of -10°C to 60°C.

Lightweight Design

The product weighs only 126 grams, and its lightweight design reduces the load on the mechanical arm, enhancing the overall system’s efficiency.

Tube Installation Method

The HEL-3/8-D-MINI solenoid valve features a tube installation method with G3/8 ports, making it easy to connect with pneumatic systems and ensuring convenient and compatible installation.

FESTO’s HEL-3/8-D-MINI solenoid valve, with its pneumatic actuation, soft sealing principle, optional installation positions, two-way two-position function, wide pressure range, high standard flow performance, corrosion resistance, environmental adaptability, lightweight design, and tube installation method, provides an efficient and reliable pneumatic control component for automation control systems. Whether it’s a production line pursuing high efficiency or an automation application requiring precise control, the HEL-3/8-D-MINI solenoid valve is an ideal choice.
